Security Evaluation of J2ME CLDC Embedded
Java Platform1
Mourad Debbabi, Mohamed Saleh, Chamseddine Talhi and Sami
Zhioua
Computer Security Laboratory,
Concordia Institute for Information Systems Engineering,
Concordia University
|
 |
ARTICLE
PDF Version |
Abstract
Java 2 Micro-Edition Connected Limited Device Configuration
(J2ME CLDC) is
the platform of choice when it comes to running mobile applications
on resourceconstrained
devices (cell phones, set-top boxes, etc.). The large deployment of
this
platform makes it a target for security attacks. The intent of this
paper is twofold:
First, we study and evaluate the security model of J2ME CLDC. Second,
we provide
a vulnerability analysis of this Java platform. The evaluated components
are: Virtual
machine, CLDC API and MIDP (Mobile Information Device Profile) API.
The
analysis covers the specifications, the reference implementation (RI)
as well as several
other widely-deployed implementations of this platform. The aspects
targeted
by this security analysis encompass: Networking, record management system,
virtual
machine, multi-threading and digital rights management. This work identifies
security
weaknesses in J2ME CLDC that may represent sources of security exploits.
Moreover,
the results reported in this paper are valuable for any attempt to test
or harden the
security of this platform.
1 INTRODUCTION
With the proliferation of mobile, wireless and internet-enabled devices
(e.g. PDAs,
cell phones, pagers, etc.), Java is emerging as a standard execution
environment due
to its security, portability, mobility and network support features.
The platform of
choice in this setting is J2ME CLDC [19, 25]. It is an enabling technology
for a
plethora of services and applications: games, messaging, presence and
availability,
web-services, mobile commerce, etc.
This platform has been deployed now by more than 20 telecommunication
operators.
The total number of deployed Java mobile devices in the market exceeds
250 million units worldwide. According to IDC, a prestigious market
research firm,
there will be more than 1.2 billion deployed Java-based mobile devices
by 2006.
J2ME CLDC gained a big momentum and is now standardized by the Java
Community Process (JCP) and adopted by many standardization bodies
such as 3GPP, OMA, etc. Another factor that has amplified the wide
industrial adoption of
J2ME is the broad range of Java-based solutions that are available
in the market.
All these factors made Java in general and J2ME in particular an
ideal solution for
software development in the arena of embedded and wireless systems.
The typical most widely deployed J2ME CLDC platform consists of several
components
that can be classified into virtual machine, APIs and tools. The
virtual machine
is the KVM [20, 26]. The APIs are CLDC [34] and MIDP[23, 25]. The
tools
are the pre-verifier and the Java code compacter. KVM (Kilobyte Virtual
Machine)
is an implementation of the Java Virtual Machine (JVM) [10]. It lies
on top of the
host operating system and its main goal is to execute compiled program
units (class
files). CLDC provides the most basic set of libraries and virtual-machine
features for
resource-constrained, network-connected devices. MIDP is a layer
on top of CLDC
configuration. It extends the latter with more specific capabilities,
namely, networking,
graphics, security, application management, and persistent storage.
The
preverifier checks all the Java classes to enforce object, stack
and control-flow safety.
This is done off-line and the result is stored as attributes in the
compiled program
units. The Java code compactor (JCC) is in charge of the romizing
process. The
latter is a feature of KVM that allows to load and link Java classes
at startup. The
idea is to link these classes off-line, then create an image of these
classes in a file
and finally to link the image with KVM.
With the large number of applications that could be available for
Java-enabled
devices, security is of paramount importance. Applications can handle
user-sensitive
data such as phonebook data or bank account information. Moreover,
Java-enabled
devices support networking, which means that applications can also
create network
connections and send or receive data. Security in all of these cases
should be a major
concern. Malicious code has caused a lot of harm in the computer
world, and with
phones having the ability to download and run applications there
is an actual risk of
facing this same threat. Currently, viruses for phones start to emerge
(e.g. Cabir),
a number of model specific attacks has been reported (e.g Nokia 6210
DoS, Siemens
S55 SMS, etc.), and mobile attacks and exploits are starting to get
attention in the
hacker community (e.g. www.defcon.org).
This paper aims to provide a careful study of the J2ME CLDC
security. The
purpose of this paper is twofold; (first) study and evaluate the
security model of
J2ME CLDC, (second) provide a vulnerability analysis of this Java
platform. In
this regard, we investigated both, the published specifications and
the available
implementations. By analyzing specifications, we provide a comprehensive
study of
the J2ME CLDC security model, pointing out possible shortcomings
and aspects
open for improvement. By investigating available implementations,
we discovered
existent weaknesses through security testing. To make the results
of our analysis
as credible as possible, we investigated several implementations
of the platform like
Sun’s RI, phone emulators, and actual phones.
By identifying weaknesses that may represent sources of security
breaches, our
security evaluation provides a starting point to a process that
aims to improve the security of J2ME CLDC, which is the final goal
of this research work.
This paper is organized into six sections beginning with the introduction.
In
section 2, we present related work concerning the comprehension
of J2ME CLDC
security and its evaluation. In sections 3 and 4, we present
the security architecture
of J2ME CLDC, followed by our evaluation of the underlying security
model. They
are followed by our vulnerability analysis, which starts by presenting
the previously
reported flaws, and then giving the actual results of our analysis.
Finally section 6
concludes the paper.
2 RELATED WORK
This section gives an overview of what has been published in
the literature regarding
J2ME CLDC security evaluation. The majority of these efforts
provided tutorials on
J2ME CLDC security and tried to evaluate the underlying security
model. Typically,
these papers contain a description of the security model
for J2ME CLDC (MIDP
1.0 and/or MIDP 2.0) followed by an evaluation of that model.
Some papers point
out weaknesses while others provide ideas to improve the
security mechanisms.
In [15], Kolsi and Virtanen, tried to evaluate the new security
features of MIDP
2.0. They started by giving an exhaustive classification
of all threats and security
needs in mobile environment, in particular for J2ME. Based
on that analysis, the
authors emphasized the security weaknesses in MIDP 1.0.
Then, the new security
mechanisms and features of MIDP 2.0 are analyzed showing
how the security problems
of MIDP 1.0 are addressed. Finally, the authors concluded
that several security
problems were addressed by MIDP 2.0, but some problems
are still present mainly
related to the PKI. These problems are illustrated in [3].
In [1], Sanjay Chadha discusses various issues about J2ME
applications. In
particular, he discusses two security concerns. First,
he points out that the J2ME
built-in security is not enough because the application
has to be delivered to the
device before it is processed through the security verification
process. He claims
that this is not sufficient in the wireless world since
it is already too late if a malign
application is delivered to a mobile device. He thinks
that applications need to be
tested for viruses and other potential malign behavior
on the server side before they
are deployed to the mobile device. Second, he highlights
the lack of DRM (Digital
Rights Management) support in J2ME. For example, most
users prefer to try an
application before making a purchasing decision. Without
such capability, users are
reluctant to buy games, which leads to lost revenue for
operators.
Also [37] presents security challenges and solutions
for J2ME-based mobile commerce
applications. Yuan and Long closely examine the potential
security advantages
of J2ME-based applications over other wireless alternatives
such as WAP and
native applications. Then, they explain the security
model available on the J2ME
platform (CLDC and CDC). As part of their discussion,
Yuan and Long suggest
some potential ways to enhance network and data security
for J2ME applications.
For example, they claim that point-to-point protocols such as SSL
are not suitable
for web services and to address this issue there is a need to an end-to-end
security
model with flexible encryption schemes. They believe that the focus
should be on securing
content rather than connection. Also, they propose to secure content
through
securing XML which is their format of choice for data communication
between J2ME
wireless applications and back-end services. Finally, they summarize
the feasibility
of developing advanced secure applications for the smallest wireless
devices using
J2ME technologies. It should be noticed also that their article is
published in 2002
and some issues discussed by the authors were addressed by new JSRs.
For example,
JSR 172 provides basic XML procession capabilities to J2ME.
It is important to note that there is a large number of efforts in
the J2ME
CLDC security literature that focus on supporting security at the application
layer
[9, 35, 11, 12, 13, 14]. These papers discuss security solutions that
do not rely on
protocols at lower layers. That is, the security related functions
are implemented in
the application (MIDlet) itself.
3 J2ME CLDC SECURITY ARCHITECTURE
The high-level J2ME CLDC architecture defines 3 layers on top of
the device’s operating
system: The virtual machine(KVM) [17], the Configuration (CLDC) which
is
a minimal set of class libraries that provide the basic functionalities
for a particular
range of devices, and the Profile (MIDP) which is an extension of the
Configuration that addresses the specific demands of a device family. At the implementation
level,
MIDP also consists of a set of Application Program Interfaces (APIs).
Applications developed for the J2ME CLDC platform (MIDlets) are downloaded
to the device in the form of two files: the Java Archive (JAR), and
the Java Application
Descriptor (JAD). The JAR is an archive file that contains the JAR
manifest,
which is a text file that contains various attributes like the MIDlet
name. It also
contains preverified class files of the MIDlet, plus any other Supporting
files needed
by the application (e.g. graphic files). One JAR file can contain more
than one
MIDlet and the set of MIDlets in a JAR file is called MIDlet suite.
The JAD on
the other hand, is a plain text file that contains several attributes
like the MIDlet
name and MIDP version needed to run the MIDlet. The JAD is also used
to give
some information about the MIDlet, such as the vendor’s name,
a small description,
etc. The software entity on the device that is responsible for MIDlet
management
is called the Application Management System (AMS), or the Java
Application Manager (JAM).
On J2ME CLDC devices security issues are classified as:
- Low-level security deals with safety issues related to
the virtual machine. In
general, the role of the low-level security mechanisms is to ensure
that class
files loaded into the virtual machine do not execute in any way
that is not allowed by the Java virtual machine specification [17].
- By application-level security, we mean that “Java applications
can access only
those libraries, system resources and other components that the device
and
the Java application environment allow it to access” [34].
- End-to-end security has a larger scope involving secure
networking. The main
objective of end-to-end security is to ensure safe delivery of
data and code
between server machines and client devices.
Low-level and application security are addressed in CLDC, while MIDP
addresses
application and end-to-end security.
CLDC Security
To understand the security model of CLDC, it is important to notice
that the
security of CLDC is affected by the absence of some general Java features
- that
are usually present in Java platforms - and that have been dropped
because of
performance and security issues. Consequently security in CLDC is characterized
by:
- No Java Native Interface (JNI): Mainly for security and
performance reasons,
JNI [16] is not implemented in CLDC. Although, a Kilo Native Interface
(KNI)
[32] is provided for J2ME CLDC, KNI does not have the ability to
dynamically load and call arbitrary native functions from Java programs
(which
could cause
significant security problems in the absence of the full Java 2
security model).
-
No user-defined class loaders: Mainly for security reasons, the class
loader
in CLDC is a built-in “bootstrap” class loader that cannot
be overridden,
replaced, or reconfigured. The elimination of user-defined class loaders
is part
of the “Sandbox” security model restrictions.
- No thread groups or daemon threads: While supporting multithreading,
CLDC
has no support for thread groups or daemon threads.
- No support for reflection: No reflection features are supported,
and therefore
there is no support for remote method invocation (RMI) or object
serialization.
Low-Level Security
Low level security in CLDC is mainly based on type safety mechanisms.
The class
file verifier is the module in charge of type safety checking.
The class file verifier
ensures that the bytecodes and other items stored in class files
cannot contain illegal
instructions, cannot be executed in an illegal order, and cannot
contain references to invalid memory locations or memory areas
that are outside the Java object memory
(the object heap) [34].
In J2ME CLDC and due to the constraints on device resources, this
is done in
two steps:
- Off-device pre-verification: During this phase, which is
performed on the development
platform, certain bytecodes will be removed, and class files
will
be augmented with additional StackMap attributes in order to speed
up the
runtime verification.
- In-device verification: The runtime verifier component
uses the additional
StackMap attributes generated by the preverifier to perform
the actual class
file verification efficiently [34].
Application-level Security
The CLDC application security is mainly ensured by adopting a sandbox
model, by
protecting system classes, and by restricting dynamic class loading:
- Sandbox Model:
- Java class files are properly verified and are valid
Java classes.
- Only a closed predefined set of Java APIs is available
to the application
programmer, as defined by CLDC, profiles and manufacturer-specific
classes.
- Downloading, installing, and managing MIDlets on
the devices takes
place at the native level inside the virtual machine.
Therefore, the application
programmer cannot modify or bypass the standard
class loading mechanisms of the virtual machine.
- The set of functions accessible to the virtual machine
is closed. Thus,
developers cannot download any new libraries containing
native functionality
or access any native functions that are not part
of the Java libraries provided by CLDC, MIDP, or the manufacturer.
-
Protecting System Classes: In CLDC, the application
programmer cannot
override, modify, or add any classes to the protected system
packages, i.e.
packages belonging to configuration, profile, or manufacturer.
Thus, the system
classes are protected from the downloaded applications. Also,
the application
programmer is not able to manipulate the class file lookup
order in any
way.
- Restrictions on dynamic class loading: One important
restriction is made on
dynamically loading class files: A Java application can load
application classes
only from its own Java Archive (JAR) file.
MIDP Security
MIDP 1.0 Security
Application security in MIDP 1.0 is based on a Java sandbox model
which was explained
earlier. It is also important to note that in MIDP 1.0, MIDlet
suites are
allowed to save data in persistent storage files (called record
stores). However, sharing
of record stores between MIDlet suites is not allowed. With respect
to end-to-end
security, MIDP 1.0 specification does not include any cryptographic
functionality.
The only network protocol provided in MIDP 1.0 is the HTTP protocol.
MIDP 2.0 Security
The difference between MIDP 1.0 security and MIDP 2.0 security
is that, in MIDP
2.0, accessing sensitive resources (APIs and functions) is
not totally prohibited.
Instead, MIDP 2.0 controls access to protected APIs by granting
permissions to
protection domains and binding each MIDlet on the device to
one protection domain.
Thus, a MIDlet will be granted all permissions provided to
the protection domain
that has been bound to it. A MIDlet is bound to one protection
domain according to
a well defined procedure that allows the AMS to authenticate
the origin of a MIDlet:
If one MIDlet can be authenticated, then it is qualified as
trusted, otherwise, it will
be qualified as untrusted. In addition, MIDP 2.0 introduces
the ability to share
record stores between MIDlet suites. The protection of record
stores is discussed
later in this section. Also, an important difference between
the security of MIDP
1.0 and MIDP 2.0 is that MIDP 2.0 provides end-to-end security
by allowing secure
networking using HTTPS protocol.
Sensitive APIs
In MIDP 2.0, some capabilities of the device are exposed to
MIDlets through a set
of APIs that are identified as sensitive and therefore
should be protected. The sensitive
APIs in MIDP 2.0 are the ones related to connectivity and
the PushRegistry
class.
Permissions and Protection Domains
Access to sensitive APIs is protected by permissions. A
protection domain defines
a set of permissions, and for each permission, the
protection domain defines the
level of access to the API protected by the permission.
The level of access can be
either Allowed or User. For the Allowed level, the
permission is granted without
involving the user. As for the User level, access to
the protected API requires
explicit authorization from the user. This authorization
can be in one the following
modes [23]:
- Blanket: The permission is valid for every invocation
of the protected API.
- Session: The permission is valid during one execution
of the MIDlet.
- Oneshot: The user must be prompted for each invocation
of the protected
API.
By default, four protection domains are provided by MIDP 2.0:
-
Minimum: This domain contains no permissions. Access is
denied for all
sensitive APIs.
-
Untrusted: Requires that sensitive APIs can only be accessed
through user
permissions.
-
Trusted: All permissions are granted.
-
Maximum: Same as trusted.
In [33] which is an addendum to the MIDP 2.0 specification, protection
domains
are categorized into four classes, namely, Manufacturer, Operator,
Trusted third
party, and Untrusted domain. Protection domains are defined in a
policy file. An
example of the policy file is given in figure 1 which is the policy
file provided with
the RI. The procedure for determining whether a MIDlet suite is trusted
is devicespecific.
Some devices might trust only MIDlet suites obtained from certain
servers. Other devices might support only untrusted MIDlet suites.
Others authenticate
MIDlet suites using the Public Key Infrastructure (PKI), which is
the case shown in
figure 1. This authentication includes certificate path validation,
signature checks
and expiration checks for the certificates.
Signing a MIDlet suite
In order to sign a MIDlet suite, the signer needs to have a private
and public
key pair, and a certificate for his public key. If this certificate
is not a certificate
authority (a certificate that is stored in the device), there should
be another certificate that vouches that the first one is valid.
If this second certificate is still not a
certificate authority, it requires a third certificate vouching for
it, and so on until a
root certificate is reached.
The procedure of signing the MIDlet consists of the execution of
the following
steps:
- The signer computes a digital fingerprint of the JAR file
by applying a hash
function (SHA-1).
- They then sign the digital fingerprint by encrypting it
with the private Key.
- The signed fingerprint is placed in the JAD file.
Figure 1: Trusting a MIDlet suite and binding it to a protection
domain
- The certificate of the public key is placed in the JAD (except
if the certificate is the root certificate, which resides on the
device), as well as the other
certificates, if any.
Persistent Storage Security
In MIDP 2.0 a MIDlet suite can save data in a persistent storage
area. The
storage unit in J2ME CLDC is the record store. Each MIDlet suite
can have one or
more record stores, these are stored on the persistent storage
of the device. Record
stores are identified by a unique full name, which is a concatenation
of the vendor
name, the MIDlet suite name, and the record store name. Within
the same MIDlet,
two record stores cannot have the same name. However, if they belong
to two
different MIDlet suites, they can have the same name since their
full names will be
Figure 2: Record Stores in MIDP. unique. The
actual structure of the record store on the device storage consists
of a
header and a body. The header contains information about the record
store while
the body consists of a number of byte arrays called records, these
contain the actual
data to be stored. Figure 2 shows the structure of the storage system.
The part
of the Java platform responsible for manipulating the storage is called
the Record
Management System (RMS).
For MIDP 1.0, record stores were not allowed to be shared among MIDlet
suites.
In MIDP 2.0, sharing of record stores is allowed; the MIDlet suite
that created the
record store can choose to make it shared or not. Moreover, the sharing
mode can
be set to read-only or read/write. Sharing information is stored in
the header of
each record store, and the default mode of sharing is private (no sharing).
End-to-end Security
MIDP 2.0 specification mandates that HTTPS be implemented to allow
secure
connection with remote sites. HTTPS implementations must provide server
authentication.
The Certificate authorities present in the device are used to authenticate
sites by verifying certificate chain provided by a server.
4 J2ME CLDC SECURITY MODEL EVALUATION
We provide in this section our evaluation of the J2ME CLDC security
model. This
section is organized into to parts:
- A comparison of the J2ME CLDC model with the security model
of J2SE.The objective of such comparison is to extract the resemblances
between
the
two models and identify mechanisms dropped for the J2ME CLDC model
or
changed to fit in embedded platforms.
- Our evaluation is presented by giving the advantages and
the drawbacks of
the security model. This evaluation covers permissions, protection
domains,
security policy, and the protection of persistent storage.
To provide a credible evaluation of the J2ME CLDC security model, we
investigated
both, the published specifications and the available implementations.
By
analyzing specifications, we provide a comprehensive study of the J2ME
CLDC
security model (see the previous section), pointing out possible shortcomings
and
aspects open for improvement. The available implementations are investigated
in order
to enhance our understanding of the J2ME CLDC security model and to
discover
existent weaknesses through security testing. It is important to mention
that we investigated
several implementations of the platform like Sun’s RI, phone emulators,
and actual phones. Our evaluation is reinforced by a compilation of
the reported
flaws related to the security of J2ME CLDC security. The results of
investigating
the implementations are reported in the Section 5, which presents a
vulnerability
analysis of the J2ME CLDC platform.
J2ME CLDC Security versus J2SE Security
The security concepts of Java 2 (permissions, protection domains,
security policy,
etc.) are not typical to the J2ME CLDC platform. They were first
introduced in the
Java 2 Platform Security Architecture [31]. This architecture defines
the security
features of J2SE platform. However, the scope, the design, and
the implementation
of these concepts vary greatly in J2ME CLDC and J2SE platforms.
In the following
we highlight the main differences between them.
J2SE platform comes with a complete and full security model (Security
Manager,
Access Controller, etc.). This model cannot be fully deployed in
J2ME CLDC
platform because of the severely constrained resources (memory
budget, processing
capabilities, and power consumption). Indeed, the security model
of J2ME CLDC
can be considered as a subset of the J2SE security model. Some
features were
disabled and others were replaced by more lightweight ones.
In the following, we consider each concept at a time and we try
to exhibit the
main differences between both security models according to that
concept. The main
concepts that we focus on are: permissions, protection domains,
security policy, and
security manager.
Permissions
A permission protects access to a system resource. The system resources
can be
connectivity protocols, files, etc. Although the purpose is the
same, two main differences
exist in how this concept is implemented in J2ME CLDC and J2SE. (First),
the number of resources protected by permissions in J2ME CLDC is
less than the
one in J2SE platform. In J2ME CLDC RI, only connectivity protocols and push functionality are guarded by permissions. We note that in more recent
JSRs, other
resources are defined to be protected by permissions (SMS and MMS
[2], Bluetooth
[36], etc). In J2SE, however, various resources are guarded by permissions
(File,
Property, Runtime, etc.). Moreover, it is possible to define new
permissions that
are more tailored to the specific needs of a given program. This
is not possible
in J2ME CLDC. For example, in the RI, all permissions are defined
in com.sun-.midp.security.Permissions class which cannot be modified
by the programmer.
This difference between the two platforms may explain the rigidity
of the J2ME
CLDC security model compared to J2SE. Indeed, since only few valued
resources
are available in J2ME CLDC, the implementation of a fine-grained
security policy
will not entail important gains. However, the resulting overhead
will be important.
(Second), Permissions in J2ME CLDC are more atomic and are limited
to either
enabling or denying access to protected resources. In J2SE, permissions
specify
more information such as the CodeBase and the actions to be allowed.
Due to the
requirements of the mobile environment, J2ME CLDC introduces the
concept of
interaction mode which is not present in J2SE. This concept results
in more involving the user when granting permissions to a given
MIDlet. We can think of the
interaction mode as a concept in J2ME CLDC to compensate the fact
that users
cannot change the security policy.
Protection Domains
In J2SE, a protection domain ProtDom is defined by a set of permissions
P and
a source S. All classes coming from S are bound to ProtDom and
are granted
permissions P. Whereas in J2ME CLDC, the protection domain ProtDom is defined
by a set of permissions P and a certificate authority CA. All
MIDlets signed by CA
are bound to ProtDom. Hence, the first difference between protection
domains in
the two security models lays in the level of granularity. In
J2SE, each class is bound
to a protection domain, whereas in J2ME CLDC each MIDlet (Java
application) is
associated with a protection domain.
The way the protection domain concept is implemented differs
in both platforms.
In J2SE, a protection domain is created by instantiating the
java.security.ProtectionDomain class.
The set of permissions associated to that protection domain
is determined based on the security policy. Hence, the protection
domain is an
object that specifies a set of permissions. In J2ME CLDC a
protection domain is
not represented by an object. It is only defined in the security
policy. Since the
security policy is not open to users for manipulation, there
is no way by which the user can add new protection domains.
A major difference between J2ME CLDC and J2SE lays in the mechanism
of
assigning protection domains to classes and MIDlets. Once a
MIDlet or class is
loaded, it should be associated to a protection domain. In
J2SE, this is done by the
class loader and is based on the origin of the code. The source
of the code can be
defined by its URL and/or the entity or entities that signed
it.
In J2ME CLDC, the association of MIDlets to protection domains
is achieved
according to the certification authority that is used to check
the signature of the
MIDlet. Indeed, the device maintains a list of root certificates.
Each certificate
is associated with a protection domain. Once a MIDlet is loaded,
its certification
chain is checked and the root certificate of this chain is
used to bind the MIDlet
to a protection domain. So Associating protection domains is
based on the root
certificates present in the device.
Security Policy
The security policy specifies which permission can be granted
to which code. In
the RI of J2ME CLDC, security policy is represented in one
policy configuration
file (policy.txt file). This file specifies for each protection
domain the associated
permissions with their interaction modes. In J2SE, the security
policy is represented
by a policy object (java.security.policy). Nevertheless, the
policy information
itself is stored typically in one or more policy configuration
files. These files are
composed of grant entries that specify the permission to be
granted with the corresponding
CodeBase and allowed actions.
In J2SE, the security policy can be changed statically or dynamically.
By statically,
we mean changing the security policy before launching the Java
Runtime
Environment (JRE). This can be achieved in two ways. Fist by
using the policy-Tool. Second by changing directly the security
policy file. By dynamically, we mean
changing the security policy while the JRE is running. This
can be achieved in two
steps. The first step is to change the security policy file
in the same way as the
static alternative. The second step is to call the refresh method. Accordingly, the
modifications to the security policy will be considered at
runtime.
In J2ME CLDC, the security policy can only be changed statically.
There is only
one alternative which is modifying directly the policy configuration
file. However,
it should be noted that on real devices, the policy configuration
file is not open to
users for manipulation.
Security Manager
The security manager is the entity responsible for checking
accesses to protected
resources. Typically, it defines several methods whose names
begin with the word “check”. In J2SE, the java.lang.SecurityManager class
represents the implementation of the security manager. The
latter defines all “check” methods. The
security manager of J2SE uses the Access Controller to decide
whether to grant a
permission requested by a given program. Actually, since JDK
1.2 all access control
checks are done by the AccessController. The securityManager classes are kept to
support compatibility with previous versions.
In J2ME CLDC, no security manager class is defined. It is up
to the MIDP
implementor to provide an implementation for this concept.
For instance, in the
RI the alternative is the Security Token (ST). Each entity
that wants to access a
protected resource needs a valid ST, that is, a ST with the
required permissions.
The SecurityToken class defines all “check” methods.
However, these methods do
not use an AccessController. As mentioned earlier, the reason
for the absence of
the AccessController is that at a given moment, only one protection
domain is in
effect. So, access control consists in checking only that protection
domain. However
in J2SE, several protection domains may be in effect at a given
moment. Therefore,
an AccessController is needed to analyze the current context
and decide whether or
not to grant a requested permission. A typical AccessController algorithm consists
in inspecting the stack [4], that is, checking the protection
domain of each frame in
the stack.
Security Model Evaluation
Now, we present our evaluation of the J2ME CLDC security model.
This evaluation
is based on our understanding of the J2ME CLDC and the specification
of security
mechanisms deployed in this platform. Before presenting our
evaluation of the J2ME
CLDC security model, it is important to explain the positive
impact of dropping
some general Java features in the J2ME CLDC platform. The eliminated
features
related to security are:
-
Java Native Interface (JNI): JNI is absent from J2ME
CLDC because it is
very expensive to be deployed in embedded devices (memory
constraints). This absence protects the platform from downloaded
native code,
which is
difficult to protect from and can seriously damage the device.
-
User-defined class loaders: The class loader in CLDC
is a built-in class that
cannot be overridden or replaced by the user. Having only
one class loader will
protect the platform from attacks that are based on user
defined class loaders,
which is one of the main attacking techniques on Java platforms
[18].
-
Support for reflection: As a result of dropping reflection
features, no support
for RMI (Remote Method Invocation) nor object serialization
are provided in
J2ME CLDC. This results in more protection of the internal
architecture from
being exposed to MIDlets.
J2ME CLDC security model is based on restricting access
to sensitive resources
on the device. Giving to a MIDlet the ability to access particular
resources isbased on the level of trust the device has for
the MIDlet. The implementation of
this model consists of the concepts of permissions, protection
domains and security
policies. Moreover certain security measures are taken by
the Record Management
System to protect data in the persistent storage of the device.
In the following
we present our comments on the previously mentioned security
features of J2ME
CLDC.
Permissions
-
The user is the weakest link in security: One
of the key features of MIDP 2.0
security model is that the device asks the user (by means
of dialog screen)
whether to allow a given MIDlet to call security-sensitive
APIs or not. The
advantage of this concept is that the user is aware of
the attempts to use
security-sensitive APIs. Also, this allows MIDlets in the
untrusted protection
domain to call protected APIs provided that the user accepts
to grant the
permissions. However, with this concept of interaction
mode goes the risk of
having the user answer automatically without checking the
displayed messages.
This may happen if the MIDlet asks for too many permissions.
Moreover, one
can maliciously develop a MIDlet that pushes the user to
ignore the displayed
messages and answer automatically just to get rid of the
annoying messages.
Hence, the strict procedure of signing MIDlets with trusted
certificates, upon
which the whole MIDP security model is based, can be circumvented
by a
precipitated permission granted by the user.
-
Programmers cannot define new permissions: Programmers
are not provided
with the ability to define new permissions. In J2ME CLDC
RI, a single class
implements all permissions and it is not possible to
define new permissions by
subclassing this class. It is interesting to have the
power of personalizing the
defined set of permissions.
-
Permissions are atomic: One MIDlet is granted
access to the resource or
not. The actions that one MIDlet can perform on the granted
resource is not
specified. It is preferred to have more detailed specification
of what a MIDlet
can perform on granted resources.
Protection Domains
Protection domain is a central concept in MIDP 2.0 security.
A protection
domain is defined as a set of permissions that will be
granted to each MIDlet that
is associated with this protection domain. According to
this point of view, defining
protection domains in J2ME CLDC is a way of organizing
permissions. Our main
critiques to the definition of protection domains in J2ME
CLDC are the following:
-
Protection domains can be misused: The task of binding
the appropriate protection
domain to a given MIDlet is critical for the security of
MIDP. When granting a set of permissions to a MIDlet, one
must be sure that the MIDlet
will not misuse the granted permissions (accidentally or
maliciously) and cause
harm to the device. Developers could guarantee that their
MIDlets are correct
and safe by signing them. But in practice, it is often
the case that a program
written by a trusted developer can make a wrong behavior.
The task of binding
MIDlets to protection domains will be more complicated
if the signer is
a third party. Third parties are often manufacturers where
the corresponding
protection domains have more granted permissions.
- Protection domains are not well standardized: In MIDP
specification, manufacturers
and operators are free to define their proper protection
domains. This
will result in a standardization problem of protection
domains. The absence of
such a standard will have a negative impact on the facility
of developing and
deploying MIDlets. A developer who wants to deploy his
MIDlets would have
to require a different protection domain for each different
manufacturer or operator.
Moreover, a developer can be obliged to change his MIDlet
if the set
of permissions required by the MIDlet do not correspond
to any permissions
set of any protection domain on the device. This would
prevent developers
from one of the main advantages of the Java programming
language, which is “Write Once, Run Everywhere”.
- No way to deny permissions of a protection domain: We found
interesting to
have the ability to deny a subset of permissions among
those already granted
by a protection domain associated with a MIDlet suite.
This is motivated by
the two following arguments:
- According to the specification of protection domains,
even if a permission
is not granted by a protection domain (either
allowed or user), a MIDlet
still has the ability to get the permission
by asking the user directly.
- A MIDlet that declares some permissions in the MIDlet-Permissions attribute,
can during execution ask the user for other permissions of
the protection domain.
The model of protection domains presented
in J2ME CLDC has room for
some refinements in order to harden the
overall security model. We believe
that denying permissions granted by the
protection domain and not required
by the MIDlet suite, will enhance considerably
the security of J2ME CLDC.
We can give the following main advantages:
- The user will be protected from being asked for
permissions that are not
granted by the protection domain. In this
case, the signing authority
will have the complete responsibility of
granting permissions to a MIDlet
suite.
- A MIDlet will no longer be able to ask for permissions
that it did not ask
for in its MIDlet-Permissions attribute.
- No technique bypassing the user - like
Siemens attacks - can be deployed
to get permissions that are denied for
one MIDlet suite.
Security Policy
The security policy in J2ME CLDC specifies protection
domains with the associated
permissions and interaction modes. Since the security
policy file defines
permissions to access sensitive resources, MIDlets do
not have the power to change
the security policy file. Access to protected resources
is critical and will cost money
to the user of the device. Thus preventing MIDlets from
modifying the security
policy is motivated by commercial and safety reasons.
At the other side, it is viewed as too rigid that the
users do not have the ability to
modify the security policy for any subset of sensitive
APIs or for the data produced
by MIDlets on the device. One possible extension to the
current security policy
model is to provide MIDlets with the power of defining
permissions to access data
in the persistent storage (which can be records in data
bases, game scores, .etc)
Persistent Storage Protection
J2ME CLDC provides a model to store application data
and protect them. Data
can be stored in a persistent storage shared by all MIDlets.
Data in record stores
can be accessed or modified only from MIDlets creating
them. The only case where
a record store can be accessed (read or read/write) by
a MIDlet other then the one
creating it, is when the creating MIDlet declares the
record store as shared record.
Our critics to this model are the following:
-
Record stores are either shared or not: This
is a rigid model because often,
MIDlets need to share their data with a specific set
of MIDlets and rarely want
to share records with all MIDlets on the device. If
the shared data is critical,
then it can be red by all MIDlets on the device. The
risk will be more serious
if the sensitive data is shared by read/write mode.
In this case, the data will
be exposed to malicious MIDlets on the device and can
be modified in a non
safe manner.
-
Data can be accessed within the device:
Critical data can be vulnerable to any
attack from outside the RMS; record stores can be
accessed from the device’s
utilities (without using a MIDlet). This is a serious
problem because record
stores will be manipulated as files (copied, renamed,
deleted, etc.).
-
No encryption used for persistent data:
No encryption method is specified in
order to protect sensitive data in the persistent
storage. Thus, no critical data
can be stored securely in the persistent storage.
5 VULNERABILITY ANALYSIS
The purpose of this section is to thoroughly investigate
the presence of vulnerabilities
in J2ME CLDC platform and to assess each found vulnerability.
Vulnerability
analysis is the process of carefully studying a system
with the purpose of detecting
security related errors. These errors may come from
faults in the system specification
or the system implementation. The presence of an error
weakens the security
structure of the system, making it vulnerable to malicious
attacks.
Approach
There are several possible strategies for detecting
vulnerabilities in software. In this
paper, two main paths were taken for this purpose.
The first path relied on inspecting
the source code (RI of J2ME CLDC), looking for
possible security related flaws.
The second path consisted of executing black box
testing (using phone emulators
and actual phones), with the purpose of finding
possible attacks on the platform.
Our vulnerability analysis is reinforced by looking
for already reported bugs, and
investigating them to assess their seriousness
from the security point of view.
The objective of security code inspection is to
look for known types of vulnerabilities
(e.g. buffer overflow vulnerability). In this
regard, a list of security checks
was compiled both for C and Java code to guide
the inspection process. Also, we
identified sensible areas in the code and investigated
them more seriously in order
to find vulnerabilities to certain known attack
scenarios. As for security testing,
test cases were designed, implemented, and executed
in order to perform attacks
compromising the security and safety of the platform.
Each success of one test case
execution will reveal the presence of some security
vulnerability in the platform.
Previously Reported Flaws
Few security flaws about J2ME CLDC have been
reported. The most serious one
is the Siemens S55 SMS flaw. Besides, several
problems about MIDP RI have been
reported.
Siemens S55 SMS
In late 2003, the Phenoelit hackers group
[24] has discovered that the Siemens
S55
phone suffers from one vulnerability
that allows malicious code on the device
to
send
SMS messages without the authorization
of the user. This attack can be carried
out
by a malicious MIDlet, which does not
have the permission to send SMS messages.
By executing the attack the MIDlet will
be able to send an SMS message without
the explicit authorization of the user.
This is due to a race condition during
which the Java code can overlay the normal
permission request with an arbitrary screen
display.
Problems on MIDP RI
The Bug Database of Sun Microsystems
contains hundreds of problems about J2ME
CLDC. However, few are related to security.
In the following we describe the problems
that we deem as relevant from the security
standpoint:
- When establishing a socket connection
(socket://hostname:portnumber),
permissions are necessarily needed.
But if one runs the RI on PC where
portnumber is
already occupied, the application does
not check for permission
[30]. Instead, it throws an IOException.
This is not correct because there
is no need to access native sockets
if application has not enough permissions.
When investigating MIDP 2.0 RI for
the
same vulnerability, the execution
results in throwing a ConnectionNotFoundException exception
which means that the permission checking
were bypassed.
- A problem has been reported on the
RSA algorithm implementation claiming
that the big number division function
checks the numerator instead of the
divisor for zero [28]. On the available
MIDP 2.0 RI, we could not be sure
of this problem because the RSA algorithm
implementation is provided in object
files (without source files).
- Basic Authentication Scheme is not
fully supported in the RI [29]. According
to the MIDP 2.0 specification, the
device MUST be capable of “responding
to
a 401 (Unauthorized) or 407 (Proxy
Authentication Required) response to an
HTTP request by asking the user for
a user name and password and re-sending
the HTTP request with the credentials
supplied. The device MUST be able
to support at least the RFC2617 Basic
Authentication Scheme” [5]. However,
the RI utilizes Basic Authentication
Scheme only in the case of MIDlet Suite
installation (to retrieve JAD and JAR).
Any other HTTP responses with 401,
407 won’t be recognized to re-send
the request with the user-supplied
credentials.
- The return value of midpInitializeMemory() method
called in main() is
never checked [27]. When memory allocation
fails, system will crash without
any way to figure out the reason
of that crash.
Vulnerability Analysis Results
This section represents the findings
of our vulnerability analysis performed
on the
J2ME CLDC platform. Results are
in the form of flaws that would
compromise
the
security and safety of the platform.
They are organized according to
the platform
component in which they were discovered
(e.g. storage system, KVM, etc.). Networking
Vulnerabilities
MIDP SSL Vulnerability
In order to establish a secure
connection with remote sites
(HTTPS), MIDP uses
the SSLv3.0 protocol. The implementation
is based on KSSL [7] from Sun
Labs.
During the SSL handshake, the
protocol has to generate random
values to be
used to compute the master secret.
The master secret is then used
to generate a
set of symmetric keys for encryption.
Hence, generating random values
that are
unpredictable is an important
security aspect of SSL.
The method PRand.generateData is used to generate random data.
This method
computes the random values progressively
16 bytes by 16 bytes. The first
chunk is
computed by applying a hash algorithm
(MD5) on the seed. Then, after
the first
chunk is copied into the random
value array, the seed is updated
and the hash
algorithm is applied a second
time to generate the second chunk.
This operation
continues until the random value
array is completely populated.
Since MD5 is deterministic,
in the case it is applied on
the
same seed, it will
generate the same “random” value.
Consequently, the challenge is “how
to update
the seed in an unpredictable
fashion?”.
The RI method used to update
the seed is called updateSeed and is given in the
following:
It is easy to notice that the seed update depends only on the system
time
(System.currentTimeMillis). Hence, in order
to obtain the random value generated
by the client, all what the attacker has to do is to guess the precise
system
time (in milliseconds) at the moment of the random value computation.
To this
end, popular Ethernet sniffing tools can be used. These tools (e.g.
tcpdump) record
the precise time they see each packet. This allows the attacker to
guess a very close
interval of the correct system time. At that moment, it remains to
try all possible
values in that interval. For example, the attack that was carried out
against the Netscape browser implementation of SSL in 1996 [6] used sniffing
tools to determine
the seconds variable of the system time. Then, to find the microseconds
variable,
every possible value of the 1 million possibilities is tried.
Unauthorized SMS Sending Vulnerability
As mentioned earlier, the Phenoelit hackers group [24] has discovered
that the
Siemens S55 phone has a vulnerability that allows malicious code
on the device to
send SMS messages without the authorization of the user. The idea was
to fill the
screen with different items when the device is asking the user for
SMS permission.
In this way, the user unwittingly will approve sending SMS messages
since he thinks
that he is answering a different question.
In order to prove this vulnerability, we developed a MIDlet that tries
to take
advantage of this flaw. The MIDlet uses two threads. The first sends
an SMS
message and the second fills the screen with other items but without
changing the
buttons of the screen. The important code chunks of this MIDlet are
illustrated in
the following:
The first thread sends the SMS message:
The second thread obscures the screen with other items:
The
key point in this attack is that only the screen is overwritten. The
buttons (soft buttons) behavior is not changed and it is still about
the SMS
message permission. We ran the MIDlet on Siemens S55 emulator using
Sun One Studio 4.
The result was as we expected: The SMS authorization dialog (i.e. send
SMS ?)
was obscured by a different item (play game). This makes the user think
that he
is answering an invitation to play a game!
Since its publication, this flaw was always bound to Siemens S55 phones.
However,
nothing was said about its applicability on other phones. We run
the previous
MIDlet on other Siemens phones emulators, namely, 2128, CF62, and
MC60. We
found that all these phones are vulnerable to SMS authorization attack.
By checking
the APIs of all these phones, we found that the SMS APIs are almost
the same,
which explains our findings.
Unlike Siemens phones, Sun RI of MIDP is not vulnerable to this attack.
Indeed,
when the device asks the user for permission, MIDP RI prevents
any modification
of the screen until an answer is received. This is achieved by
preemptDisplay method, which locks access to the display until the user provides
an answer, then
the display is unlocked by the doneDisplay method.
Storage System Vulnerabilities
Detailed analysis of the RMS using MIDP specifications and RI revealed
the vulnerabilities listed below.
Unprotected Data Vulnerability
Data in record stores are not protected against malicious attacks.
There is
no mention in the specification of protecting sensitive
user data for example with
encryption and/or passwords. Data can be vulnerable to
any attack from outside
the RMS, such as when transferring data to or from a
PC for backup and restoring.
Moreover the whole storage system in MIDP can be accessed
from any other file
system on the device. This can happen in the case of
PDAs, where the operating
system can access the actual files of the record stores
on the device storage and hence
any sensitive data stored in them. An example of such
access can be performed using
the FExplorer software. This example is discussed with
further issues in the next
sections.
Managing the Available Free Persistent Storage Vulnerability
When a MIDlet needs to store information in the persistent
storage, it can create
new records. Since the persistent storage is shared
by all Midlets installed on
the device, restrictions must be made on the amount
of storage attributed to each
MIDlet. This is motivated by the fact that embedded
devices have limited memory
resources. As we can see from the MIDP specification,
there is no restriction on
the size of storage granted to one MIDlet, which
means that one cannot prevent
any MIDlet from getting all the available free space
on the persistent storage for its record stores
Figure 3: Various Levels of Abstraction
in APIs for Mobile Devices. By
allowing this, all other MIDlets will be prevented
from getting additional
persistent storage (that can be vital for their life
cycle). This vulnerability
was discovered in the MIDP RI as well as in the Wireless
Toolkits.
Unprotected Internal APIs Vulnerability
MIDP APIs were designed to provide all the functionalities
needed by the developer,
and they should be the only APIs available for direct
use by developers.
However, these are high level API’s designed
to make programming easier, so they
need the help of other low level APIs and native
methods to deal with the device
hardware. The low level APIs are closer to the device
hardware, and therefore are
more difficult to program, but they have more privileges
and less restrictions in order
to be able to have more freedom when dealing with
the device hardware. This
should not affect the system security, provided that
access to these APIs is restricted
to the higher level APIs. In other words, developers
should not have access to these
low level APIs. This is not the case with the J2ME
CLDC RI. Figure 3 illustrates
how the different levels of APIs are accessed.
In order to exhibit the danger of having the programmer
access to internal APIs,
we give the example of deleting a record store
belonging to another MIDlet. In
the storage system of MIDP, RecordStore is one
high level API that provides the
functionalities needed by the developer to manipulate
record stores such as opening,
closing, deleting, etc. This class also checks
for access rights before doing such
actions, this is to protect data security and integrity,
for instance no MIDlet is
allowed to delete a record store of another MIDlet.
There is another low level class,
which is RecordStoreFile, this class is closer
to the device hardware, it calls native
methods and provides services to the RecordStore class. This class should not be
available for direct use by developers, because
it has more access rights and bypasses
the security checks. In RI, this class can be used
directly by programmers, which
can compromise data security. We were able to use
this vulnerability to have a
MIDlet that deleted a record store belonging to
another MIDlet.
First, a MIDlet rmstest was developed that creates
a private (unshared) record
store called attack. Then, another MIDlet was
developed which uses the methods
of the RecordStoreFile class to bypass security
checks and delete the record store
created by the previous MIDlet:
The
first MIDlet was run first to create the record store,
then the second one
was run and succeeded to delete it.
Retrieving and Transferring JAR Files from a Device
A typical scenario of getting a MIDlet into a device
is to connect to a provider
web site and to download a chosen MIDlet usually
after paying a certain amount of
money. Once a MIDlet is installed on a device
the user should be able to perform two
kinds of operations, namely, executing and uninstalling
the MIDlet. If, in addition,
the user has the capability to transfer the MIDlet
and make it run on another device,
it results in a problem for the provider of the
MIDlet. Indeed, this allows for illegal
redistribution of MIDlets and consequently for
financial losses.
In our experiments, we succeeded to transfer
MIDlets from one device to another.
This was possible thanks to a free software
for Series 60 phones [21]. The FExplorer
software [8] makes it possible to navigate
through the files and MIDlets installed on
the device just like navigating on a desktop
file system. In order to transfer MIDlet
JAD and JAR files into a second device, all
we had to do is to go to the location
where these files are stored and choose any
sending option. This operation is also
possible in all Series 60 devices. These include
Samsung, Siemens, Panasonic and
mainly Nokia devices [21].
Finally, it is important to note that transferring
is not possible for DRM (Digital
Right Management) protected MIDlets (protection
should be at least by the forward
lock mode [22]).
Retrieving and Transferring MIDlet Persistent
Data
Using FExplorer software, (in addition
to JAR and JAD files) it is also possible
to transfer MIDlet persistent data from
a device to another. Indeed, rms.db file
that holds all MIDlet persistent
data is located in the same location
as JAD and JAR
files and can be transferred following
the same steps. Moreover, the DRM issue
is
no more valid for rms.db. That is,
even if the MIDlet is DRM protected
the rms.db
can be transferred because the DRM
protection holds only for JAR files
[22]. This
may have a serious impact on the privacy
of the MIDlet since it is possible
to tamper
with its persistent data.
KVM Vulnerabilities
Buffer Overflow Vulnerability
Buffer overflow is a well-known problem
and may result in many security
breaches.
It occurs when the program does
not perform bounds checking of
buffers
before copying.
A typical scenario consists in
the following: a buffer (e.g.
an array
of integer)
is located in the execution stack.
The program tries to overwrite
that buffer with
another one using for example
strcpy function (for C code).
The danger
occurs
when the second buffer (source)
is larger than the first (destination).
In that case
some values in the execution
stack may be overwritten. Among
these
values it is
possible to overwrite the return
address of the current function.
By overwriting
that address, the attacker will
be able to jump to whatever code
he
wants. This allows
the attacker to execute the code
that he wants with the
same
privilege as the
program.
By inspecting the source code
of KVM, we identified a memory
overflow
vulnerability.
The vulnerable code is the
following code in native.c file:
This code throws an exception if a native method is declared in a class
file without
implementing it elsewhere. The code does not check the size of the
message that will
be stored in str_buffer. Knowing that str buffer
is a global variable declared
as an array of characters (char str_buffer[512];),
it is clear that the code might
result in a strange behavior if the size of the string to be stored
in str_buffer exceeds 512. One part of
the string to be stored in str buffer is the name of the
invoked native method. Knowing that no restrictions are imposed by
the VM on the
size of method or field names, we wrote a simple Java program that
declares a native
method name counting 2000 characters (greater than the str_buffer size).
This
native method is declared without giving any implementation (in order
to force the
throw of the exception). When the exception is thrown, the native method
name is
concatenated in str_buffer overwriting more than 1500 characters in
the memory
segment. The Java program exploiting this vulnerability is the following:
6 CONCLUSION AND FUTURE WORK
In this paper, we provide a careful study of J2ME CLDC security. We
started by
presenting the security architecture of this Java platform, followed
by our evaluation
of the underlying security model. In our study, we investigated the
existing implementations
of the platform in order to look for vulnerabilities. Actual phone
models
were tested and an important set of attack scenarios were designed
and executed.
We showed that the J2ME CLDC security model needs some refinements
(e.g. permissions
and protection domains). Moreover, we demonstrated the presence of
some
vulnerabilities exist in the RI of MIDP 2.0 (e.g. SSL implementation).
Some phones
were also shown to be vulnerable to security attacks like the Siemens
SMS attack,
while other phones followed a restrictive approach in implementing
the J2ME CLDC
platform. With this study in hand, improvements can be performed to
harden the
J2ME CLDC security. Therefore, the security model can be improved by
fixing the
discovered vulnerabilities and by proposing new security extensions.
Footnote:
1 The research published in this paper
is the result of a fruitful collaboration between Concordia University
and Alcatel Canada. It is supported by an NSERC (Natural Sciences and
Engineering Research Council) CRD (Collaborative Research and Development)
grant.
REFERENCES
[1] S. Chadha. J2me issues in the real wireless world. http://www.microjava.com/articles/perspective/issues?content_id=4323,
January 2003.
[2] J. Eichhloz. JSR 205 Wireless Messaging API 2.0, June 2004.
[3] Carl Ellison and Bruce Schneier. Ten risks of PKI: What you’re
not being told
about Public Key Infrastructure. Computer Security Journal, 16(1):1–7,
2000.
[4] Cédric Fournet and Andrew D. Gordon. Stack inspection:
theory and variants. In Proceedings of the 29th ACM SIGPLAN-SIGACT
symposium on
Principles of programming languages, pages 307 –318. ACM Press, 2002.
[5] J. Franks, P. Hallam-Baker, J. Hostetler, S. Lawrence, P. Leach,
A. Luotonen,
and L. Stewart. RFC 2617: HTTP Authentication: Basic and Digest Access
Authentication, June 1999.
[6] Ian Goldberg and David Wagner. Randomness and the Netscape browser.
Dr.
Dobb’s Journal of Software Tools, 21(1):66, 68–70, January
1996.
[7] Vipul Gupta and Sumit Gupta. KSSL: Experiments in Wireless Internet
Security.
Technical Report TR-2001-103, Sun Microsystems, Inc, Santa Clara,
California, USA, November 2001.
[8] D. Hugo. FExplorer Web Site. http://users.skynet.be/domi/fexplorer.htm.
[9] Wassim Itani and Ayman Kayssi. J2me application-layer end-to-end
security
for m-commerce. Journal of Network and Computer Applications, 27(1):13–32,
January 2004.
[10] G. Steele J. Gosling, B. Joy and G. Bracha. The Java Language
Specification
Second Edition. The Java Series. Addison-Wesley, Boston, Mass., 2000.
[11] J. Knudsen. MIDP Application Security 1: Design Concerns and
Cryptography.
http://developers.sun.com/techtopics/mobility/midp/articles/security1/,
September 2002.
[12] J. Knudsen. MIDP Application Security 2: Understanding SSL and
TLS. http://developers.sun.com/techtopics/mobility/midp/articles/security2/,
October 2002.
[13] J. Knudsen. MIDP Application Security 3: Authentication in MIDP.
http://developers.sun.com/techtopics/mobility/midp/articles/security3/,
December 2002.
[14] J. Knudsen. MIDP Application Security 4: Encryption in MIDP.
http://developers.sun.com/techtopics/mobility/midp/articles/security4/,
June 2003.
[15] O. Kolsi and T. Virtanen. MIDP 2.0 Security Enhancements. In
Proceedings
of the 37th Annual Hawaii International Conference on System Sciences
(HICSS’04) - Track 9 - Volume 9, Washington DC, USA, dec 2004.
[16] Sheng Liang. Java Native Interface: Programmer’s Guide
and Specification.
Addison-Wesley, Reading, MA, USA, 1999.
[17] T. Lindholm and F. Yellin. The Java Virtual Machine Specification
(Second
Edition). Addison Wesley, April 1999.
[18] LSD Research Group. Java and Java Virtual Machine Security, Vulnerabilities
and their Exploitation Techniques. http://www.blackhat.com/presentations/bh-asia-02/LSD/bh-asia-02-lsd-article.pdf,
September
2002.
[19] Sun MicroSystems. Connected, Limited Device Configuration. Specification
Version 1.0, Java 2 Platform Micro Edition. Technical report, Sun
MicroSystems,
California, USA, May 2000.
[20] Sun MicroSystems. KVM Porting Guide. Technical report, Sun MicroSystems,
California, USA, September 2001.
[21] Nokia. Series 60 Platform. http://www.nokia.com/nokia/0,8764,46827,00.html.
[22] OMA. Implementation Best Practices for OMA DRM v1.0 Protected
MIDlets,
May 2004.
[23] J. Van Peursem. JSR 118 Mobile Information Device Profile
2.0, November
2002.
[24] Phenoelit Hackers Group. http://www.phenoelit.de/, 2003.
[25] Roger Riggs, Antero Taivalsaari, Mark VandenBrink, and
Jim Holliday. Programming
wireless devices with the Java 2 platform, micro edition:
J2ME Connected
Limited Device Configuration (CLDC), Mobile Information
Device Profile (MIDP). Addison-Wesley, Reading, MA,
USA, 2001.
[26] T. Sayeed, A. Taivalsaari, and F. Yellin. Inside
The K Virtual Machine. http://java.sun.com/javaone/javaone2001/pdfs/1113.pdf,
Jan 2001.
[27] Bug 4824821: Return value of midpInitializeMemory
is not checked. http://bugs.sun.com/bugdatabase/view_bug.do?bug_id=4824821,
February 2003.
[28] Bug 4959337: RSA Division by Zero. http://bugs.sun.com/bugdatabase/view_bug.do?bug_id=4959337,
November 2003.
[29] Bug 4963644: Basic Authentication Scheme is
not fully supported . http://bugs.sun.com/bugdatabase/view_bug.do?bug_id=4963644,
December 2003.
[30] Bug 4802893: RI checks sockets before checking
permissions. http://bugs.sun.com/bugdatabase/view_bug.do?bug_id=4802893,
January 2004.
[31] Sun Microsystems. Java 2 Platform Security
Architecture. http://java.sun.com/j2se/1.4.2/docs/guide/security/index.html,
2002.
[32] Sun Microsystems. KNI Specification
K Native Interface (KNI)
1.0. http://www.carfield.com.hk/java_store/j2me/j2me_cldc/doc/kni/html/index.html,
October 2002.
[33] Sun Microsystems. The Recommended Security Policy for GSM/UMTS
Compliant
Devices, Addendum to the Mobile Information Device Profile version
2.0,
2002.
[34] A. Taivalsaari. JSR 139 J2ME Connected Limited Device Configuration
1.1,
March 2003.
[35] The Legion of the Bouncy Castle. Bouncy Castle Cryptography
API. http://www.bouncycastle.org, 2004.
[36] R. Viswanathan. JSR 82 Java APIs for Bluetooth, Mars 2002.
[37] Michael Juntao Yuan and Ju Long. Securing wireless j2me. http://www-106.ibm.com/developerworks/java/library/wi-secj2me.html,
June 2002.
About the authors
|
|
Mourad Debbabi holds Ph.D. and
M.Sc. degrees in computer science from
Paris-XI Orsay, University, France. He published more than 80
research papers
in journals and conferences on computer security, formal semantics,
Java security
and acceleration, cryptographic protocols, malicious code detection,
programming
languages, type theory and specification and verification of safety-critical
systems. He is a Full Professor and the Associate Director of
the Concordia
Institute for Information Systems Engineering, Concordia University,
Montreal,
Quebec, Canada. He is the Specification Lead of four Standard
JAIN (Java
Intelligent Networks) Java Specification Requests (JSRs) dedicated
to the elaboration
of standard specifications for presence and instant messaging.
In the
past, he served as Senior Scientist at the Panasonic Information
and Network
Technologies Laboratory, Princeton, New Jersey, USA; Associate
Professor at
the Computer Science Department of Laval University, Quebec, Canada;
Senior
Scientist at General Electric Research Center, New York, USA;
Research
Associate at the Computer Science Department of Stanford University,
California,
USA; and Permanent Researcher at the Bull Corporate Research Center,
Paris, France. He can be reached at debbabi@ciise.concordia.ca.
See also
http://www.ciise.concordia.ca/~debbabi.
|
|
|
Mohamed Saleh is
a Ph.D. student at Concordia Institute for Information Systems
Engineering (CIISE), Concordia University, Montreal, Quebec, Canada.
He is a member of the Computer Security Laboratory (CSL) at CIISE.
He is
pursuing a Ph.D. thesis on the specification and analysis of security
protocols
using game semantics. He can be reached at m_saleh@ece.concordia.ca.
|
|
|
Chamseddine Talhi is a researcher
at CSL (Computer Security Laboratory)
research group at Concordia Institute for Information Systems
Engineering,
Concordia University, Montreal, Quebec, Canada. He holds an M.Sc.
degree
from Constantine University, Algeria. He is pursuing a Ph.D. thesis
on the security
of embedded Java platforms. He is interested in characterizing
enforceable
security policies in resource-constrained platforms. In the past
years, he worked
on formal specification and verification of telecommunication
services. He participated
in the design and the implementation of a Java optimizing compiler
for J2ME/CLDC. He can be reached at talhi@ciise.concordia.ca. |
|
 |
Sami Zhioua was a researcher at
CSL (Computer Security Laboratory) research
group at Concordia Institute for Information Systems Engineering,
Concordia
University, Montreal, Quebec, Canada. The main topic of his research
activities
is the acceleration of Java in the context of embedded systems.
The goal
of his research is to design and implement new techniques in order
to improve
the performance of embedded Java virtual machines. He participated
in the
design and implementation of a dynamic optimizing compiler for
J2ME/CLDC.
He can be reached at zhioua@ciise.concordia.ca.
|
Cite this column as follows: Mourad Debbabi, Mohamed Saleh, Chmseddine
Talhi and Sami Zhioua: “Security Evaluation of J2ME CLDC Embedded
Java Platform”, in Journal of Object Technology, vol. 5, no. 2, March-April
2006, pp. 125-154, http://www.jot.fm/issues/issue_2006_03/article2
|
